PLC
MELSEC iQ-F FX5U
FX5U Series
Brand: Mitsubishi Electric
Technical Specifications
- Program Capacity: 64k steps.
- I/O Capacity: Supports up to 256 digital I/O points (expandable to 512 points with remote I/O).
- Power Options: Available in 100–240 V AC and 24 V DC versions.
- Storage: Includes a built-in SD memory card slot for data logging, program updates, and backup.
- Programming Software: Programmed using the intuitive GX Works3 environment, which supports multiple languages including Ladder, Structured Text (ST), and Function Block Diagram (FBD).
Key Features & Performance
- Ultra-High-Speed Processing: Features a high-speed CPU with a basic instruction processing speed (LD) of 34 ns, enabling rapid and accurate control of complex processes.
- Built-in Ethernet & Serial Ports: Equipped with a standard Ethernet port and an RS485 port, facilitating seamless integration with networks, HMIs, and SCADA systems.
- Advanced Positioning Control: Supports built-in 4-axis positioning (up to 200 kHz) and can be expanded for more complex multi-axis motion applications.
- Integrated Analog I/O: Includes two built-in analog inputs and one analog output as standard, allowing for sensor feedback and actuator control without additional modules.
- Maintenance-Free Design: Uses non-volatile memory for programs, eliminating the need for a battery to retain data under standard conditions.
- Enhanced Security: Protects intellectual property and prevents unauthorized access with features like security keys and IP address filtering.
Common Industrial Applications:
The FX5U is widely used across various sectors including:
The FX5U is widely used across various sectors including:
- Manufacturing: Assembly lines, CNC machines, and robotic arms.
- Packaging Systems: High-speed filling, labeling, and sealing machinery.
- Process Control: Reliable regulation of temperature, pressure, and flow in chemical or food industries.
- Building Automation: Efficient control of HVAC, lighting, and security systems.
